Introducing the S-1803 Professional Column PA System
For DJs, bands, and live performers, a truly reliable PA system is about far more than simply being "loud enough". In the past, the S-1503 has consistently been one of our best-selling column PA systems. With its outstanding sound quality and simple setup, it has become the long-term choice for many professional DJs and live performers. As more customers began using the S-1503 column array speakers for outdoor events and larger venues, we've received extensive feedback and suggestions—specifically, requests for better sound coverage in outdoor and medium-to-large indoor settings. Therefore, EXOTON is proud to introduce the all-new S-1803—a 3000W 18-inch powered column speaker system. Building on the strengths of the S-1503, it has been upgraded to a true three-way design, featuring a powerful 18-inch subwoofer and an RS485 network interface, further enhancing overall sound depth and audio performance in medium-to-large spaces.
True Three-Way Design for Professional Column Speaker
In traditional two-way systems, the low-frequency driver is often responsible for reproducing both low frequencies and the main body of instrumental sounds. This not only risks masking midrange details at high volumes but also results in less pure bass reproduction. The S-1803's three-way design incorporates a dedicated midrange driver, enabling more precise reproduction of vocals and instruments such as guitars. At the same time, the woofer no longer needs to handle unnecessary frequency bands, allowing it to focus solely on low-frequency output. For bands and live performances, the S-1803 column speaker system delivers clearer, more prominent sound and a more layered audio experience.
The S-1803's three-way audio architecture integrates:
l 1 × 18-inch woofer (4-inch voice coil)
l 4 × 5.5-inch neodymium mid-high drivers
l 1 × 1-inch voice coil driver
New Input and Output Options for the Column PA System
The S-1803 column speaker is equipped with a professional-grade RS485 network port and XLR input/output connectors, offering users convenient and versatile connection options.
Through the RS485 network connection, users can easily adjust volume, EQ settings, DSP presets, and system status.
The XLR connectors are used to connect to mixing consoles, microphones, and other professional audio equipment, ensuring stable, low-noise audio transmission between devices.
4 DSP Preset Modes for Various Column Array Speaker Applications
Different event scenarios have varying requirements for sound performance. Therefore, the S-1803 column array speakers feature 4 built-in professional DSP preset modes to adapt to different live sound reinforcement needs.
Standard Mode: This is the default standard mode, which reproduces natural vocals and music with more pronounced bass compared to other modes, making it suitable for most everyday scenarios;
Long Throw Mode: This mode boosts mid-to-high frequencies, making sound clearer at long distances. It is suitable for outdoor venues and long-throw applications, providing good coverage for listeners in the back rows;
Down Fill Single Box Mode: This mode improves sound uniformity in the area directly in front of the speaker, making it suitable for small events and scenarios using a single speaker;
Monitor Mode: This mode is optimized for stage monitoring, reducing frequencies prone to feedback. Select this mode when using the column speaker as a monitor for performances.
Classic Design and Configuration of the Column Array Speakers
l Bluetooth Connectivity and TWS (True Wireless Stereo)
l High-Strength Steel Grille
l High-Quality Birch Plywood Enclosure
l Polyurea Spray Coating
S-1803 Column Speaker Power and Acoustic Specifications
Peak Power: 3000W
Power Rating (AES): 1500W
Frequency Response: 40 Hz – 20 kHz
Sensitivity: 97.5 dB
Max SPL: 128 dB
Nominal Impedance: 2 Ohms
Accessories for the S-1803 Column PA System
Since the official launch of the S-1803 column array speakers, we have actively gathered feedback from numerous customers. Based on this feedback, we have continuously optimized the product and its accessories to better suit everyday use scenarios. To this end, we have developed the following accessories for S-1803 owners.
1. Casters (For transport and portability)
The amplifier panel of the S-1803 subwoofer enclosure features 16 pre-drilled mounting holes for standard 3-inch casters, allowing users to install them as needed for transportation.
Caster Specifications:
2. 91cm Extension Pole (To raise the top column speaker height)
The long extension pole helps raise the upper section of the S-1803 column speaker to a higher installation height, improving the projection of the tweeter.
Extension pole length: 91 cm (35.83")
Elevation height: 75 cm (29.53")
That concludes our comprehensive overview of the S-1803. If you're looking for a professional column PA system that delivers powerful bass, wide coverage, and professional-grade sound quality, the S-1803 is the perfect choice for you!
